ASHAR, 218180063 (2025) RANCANG BANGUN ALAT PENCAMPUR MINUMAN GELAS OTOMATIS BERBASIS ARDUINO. Other thesis, UNIVESITAS MUHAMMADIYAH PAREPARE.
SAMPUL_218480063_ASHAR_ELEKTRO.pdf
Download (136kB)
SKRIPSIPENDAHULUAN_ASHAR_ELEKTRO-2-13.pdf
Download (693kB)
ISI_218480063_ASHAR_ELEKTRO.pdf
Download (1MB)
LAMPIRAN_218480063_ASHAR_ELEKTRO.pdf
Download (621kB)
JURNAL_218480063_ASHAR_ELEKTRO.pdf
Download (802kB)
JURNAL_218480063_ASHAR_ELEKTRO.pdf - Published Version
Download (802kB)
Abstract
This study aims to design and develop an automated cup beverage mixer based on the Arduino Mega 2560. The system is equipped with an infrared sensor for cup detection, a water flow sensor to measure liquid volume, and motor pumps with a gearbox motor as actuators. The software was developed using Arduino IDE with workflow illustrated in a flowchart. Experiments were conducted using water and tea at volumes of 20 ml, 30 ml, and 40 ml for water, and 40 ml, 50 ml, and 60 ml for tea. Water tests achieved average accuracy rates of 90% at 20 ml, 88% at 30 ml, and 84.58% at 40 ml. Tea tests yielded 85.25% accuracy at 40 ml, and improved to 90% at both 50 ml and 60 ml. The average filling time ranged from 8 to 10 seconds per cycle, while the maximum error rate did not exceed 25%. The findings demonstrate that the system operates effectively and consistently, with an overall filling success rate between 85% and 95%. This device shows potential applications in households, cafes, and small-scale beverage industries.
| Item Type: | Thesis (Other) |
|---|---|
| Subjects: | Sains dan Teknologi |
| Divisions: | Fakultas Teknik > Teknik Elektro |
| Depositing User: | Saeqal Firdaus |
| Date Deposited: | 29 Oct 2026 00:10 |
| Last Modified: | 29 Oct 2026 00:10 |
| URI: | https://repository.umpar.ac.id/id/eprint/1191 |
