Sistem Kendali Stabilizator Sudut dan Arah berbasis Arduino

ILHAM, 218180052 (2025) Sistem Kendali Stabilizator Sudut dan Arah berbasis Arduino. Other thesis, UNIVESITAS MUHAMMADIYAH PAREPARE.

[thumbnail of Sampul Artikel] Image (Sampul Artikel)
SAMPUL ILHAM_218180052_TEKNIK_ELEKTRO.pdf - Cover Image

Download (84kB)
[thumbnail of Pendahuluan Artikel] Text (Pendahuluan Artikel)
PENDAHULUAN ILHAM_218180052_TEKNIK_ELEKTRO.pdf - Supplemental Material

Download (504kB)
[thumbnail of BAB/Isi Artikel] Text (BAB/Isi Artikel)
ISI ILHAM_218180052_TEKNIK_ELEKTRO.pdf - Supplemental Material

Download (1MB)
[thumbnail of Lampiran Artikel] Text (Lampiran Artikel)
LAMPIRAN ILHAM_218180052_TEKNIK_ELEKTRO.pdf - Supplemental Material

Download (140kB)
[thumbnail of Artikel] Text (Artikel)
JURNAL ILHAM_218180052_TEKNIK_ELEKTRO.pdf - Published Version

Download (475kB)

Abstract

A This research aims to design and implement a direction/angle control and stabilizer system based on Arduino, using the Qibla direction as a case study. The system utilizes an HMC5883L magnetometer sensor to detect direction based on the Earth’s magnetic field, a stepper motor as the actuator, and an Arduino Uno microcontroller as the main controller. The system is capable of automatically adjusting and maintaining its orientation toward a target angle, even when external disturbances such as vibrations occur. From the sensor data, the heading angle is calculated using the arctangent function (atan2) of the magnetic field values on the X and Y axes. when the X-axis reads around 120.42° and the error detected is 171.58°, the system determines the Qibla direction by calculating the total heading to be approximately 292°, the intended target. Testing was conducted using both clockwise and counter-clockwise rotations, and results show that the system accurately reaches the target with a maximum error tolerance of ±0.5°. Corrections are visualized through data and graphs that show decreasing step sizes as the target angle is approached. This study confirms the system’s effectiveness for precision direction indication and potential for further development in navigation and worship aids.

Item Type: Thesis (Other)
Uncontrolled Keywords: Arduino; angel stabilizer; Stepper motor; direction; Control System
Subjects: Sains dan Teknologi
Divisions: Fakultas Teknik > Teknik Elektro
Depositing User: Saeqal Firdaus
Date Deposited: 27 Oct 2026 01:42
Last Modified: 27 Oct 2026 01:42
URI: https://repository.umpar.ac.id/id/eprint/1173
