SISTEM INSTRUMENTASI KEMIRINGAN MENGGUNAKAN ACCELEROMETER DAN GYROSCOPE TERINTEGRASI

FAJRULLAH HATTA, 220 180 029 (2025) SISTEM INSTRUMENTASI KEMIRINGAN MENGGUNAKAN ACCELEROMETER DAN GYROSCOPE TERINTEGRASI. Other thesis, UNIVESITAS MUHAMMADIYAH PAREPARE.

[thumbnail of Sampul] Image (Sampul)
SAMPUL _220180029_Fajrullah Hatta_Teknik Elektro.pdf - Cover Image

Download (163kB)
[thumbnail of Pendahuluan] Text (Pendahuluan)
PENDAHULUAN_220180029_Fajrullah Hatta_Teknik Elektro.pdf - Supplemental Material

Download (1MB)
[thumbnail of BAB/Isi] Text (BAB/Isi)
BAB ISI _220180029_Fajrullah Hatta_Teknik Elektro.pdf - Supplemental Material

Download (1MB)
[thumbnail of Lampiran] Text (Lampiran)
LAMPIRAN _220180029_Fajrullah Hatta_Teknik Elektro.pdf - Supplemental Material

Download (1MB)
[thumbnail of Artikel] Text (Artikel)
Jurnal Fajrullah Hatta.pdf - Published Version

Download (543kB)

Abstract

The advancement of navigation systems, robotics, and structural monitoring technologies has increased the demand for accurate, responsive, and reliable tilt measurement instruments. Although accelerometers and gyroscopes are the primary sensors used in tilt detection, each has inherent limitations: accelerometers are susceptible to noise and mechanical vibrations, while gyroscopes suffer from drift over time. Without effective integration, angular measurements become unstable and unreliable. Therefore, an efficient sensor fusion algorithm is required to combine the strengths of both sensors and minimize measurement errors. This research aims to design an integration method and signal processing algorithm based on the complementary filter to produce accurate and stable angle readings, as well as to develop a data acquisition system and user interface capable of converting raw sensor data into precise, rapid, and easily interpretable tilt information. The methodology employs an experimental approach consisting of system design (hardware and software), prototype implementation, performance testing, and data analysis, using a prototyping development model as the framework. The system is built using an MPU6050 sensor, Arduino Nano, 16x2 I2C LCD, and a buzzer, with power optimization achieved through an 18650 battery. The test results indicate that the system provides angle measurements close to the reference values, with an average error of 0.33° across the 0°-90° range. The system also successfully displays tilt information in real-time with directional indicators (using symbols ^, v, >, <) and audio feedback when the device is in a stable position. Therefore, this instrument is proven to be accurate, responsive, and user-friendly and suitable for use in educational applications, robot balancing, or simple structure monitoring.

Item Type: Thesis (Other)
Uncontrolled Keywords: sensor fusion, MPU6050, Arduino Nano, tilt angle, data acquisition system
Subjects: Sains dan Teknologi
Divisions: Fakultas Teknik > Teknik Elektro
Depositing User: Saeqal Firdaus
Date Deposited: 29 Oct 2026 00:23
Last Modified: 29 Oct 2026 00:23
URI: https://repository.umpar.ac.id/id/eprint/1215
