PENGEMBANGAN E-PARKIR BERBASIS IOT MENGGUNAKAN KARTU SURAT IZIN MENGEMUDI (SIM)

ALI BABA, 220180012 (2025) PENGEMBANGAN E-PARKIR BERBASIS IOT MENGGUNAKAN KARTU SURAT IZIN MENGEMUDI (SIM). Other thesis, UNIVESITAS MUHAMMADIYAH PAREPARE.

[thumbnail of Sampul Artikel] Image (Sampul Artikel)
sampul.pdf - Cover Image

Download (44kB)
[thumbnail of Pendahuluan Artikel] Text (Pendahuluan Artikel)
Pendahuluan_220180012_ALI BABA_ELEKTRO.pdf - Supplemental Material

Download (934kB)
[thumbnail of BAB/Isi] Text (BAB/Isi)
Isi_220180012_ALI BABA_ELEKTRO (1).pdf - Supplemental Material

Download (1MB)
[thumbnail of Lampiran] Text (Lampiran)
Lampiran_220180012_ALI BABA_ELEKTRO (2).pdf - Supplemental Material

Download (803kB)
[thumbnail of Artikel] Text (Artikel)
Jurnal Ali Baba Teknik. Elektro .pdf - Published Version

Download (865kB)

Abstract

Parking problems in public areas such as campuses, offices, and shopping centers often cause queues and levy leakage due to conventional systems that are still manual and not integrated. To overcome this, an efficient, safe, and automated parking system is needed. This research aims to develop an Internet of Things (IoT)-based e-Parking system by utilizing a Driver's License (SIM) card as a medium for user identification and authentication. The system consists of two main modules: balance top-up and parking entry/exit access. The components used include ESP32, RFID reader RC522, servo motor MG996R, OLED 128x32, buzzer, and push button. The top-up process is carried out by reading the RFID-based SIM card, selecting the nominal (Rp20,000–Rp100,000), then the data is sent to the server via a Wi-Fi connection. Test results show that the system is able to detect unregistered cards and perform automatic registration. The system also successfully deducts an automatic balance of Rp2,000 upon exit. From six entry and exit tests using the UID DA27574D card, the balance decreased from Rp20,000 to Rp14,000 according to system logic. The system's response to the card's insufficient balance was indicated by a warning message and the barrier remained closed. These results demonstrate that the developed e-Parking system works effectively and can improve transparency and security in digital-based parking management.

Item Type: Thesis (Other)
Uncontrolled Keywords: e-Parking; IoT; RFID; SIM card; top-up system
Subjects: Sains dan Teknologi
Divisions: Fakultas Teknik > Teknik Elektro
Depositing User: Saeqal Firdaus
Date Deposited: 29 Oct 2026 00:17
Last Modified: 29 Oct 2026 00:17
URI: https://repository.umpar.ac.id/id/eprint/1194
